The Eighteeth PEN-E LED Curing Pen is a cutting-edge, portable curing device designed for maximum efficiency and precision in dental procedures. With 5 customizable curing programs, it provides flexibility for various clinical situations, ensuring optimal results across different materials and procedures. This curing pen offers a balance of power, convenience, and user-friendly design, making it an essential tool for modern dental practices.
Working Modes:
Normal Mode (P1):
Light intensity: 1200mW/cm²
Time settings: 5s, 10s, 15s, 20s, 25s, 30s, 35s, 40s
High Mode (P2):
Light intensity: 2000mW/cm²
Time settings: 1s, 3s, 5s, 10s
Ultra Mode (P3):
Light intensity: 3000mW/cm²
Time settings: 1s, 3s, 5s
Pulse Mode (P4):
Light intensity: 1200mW/cm²
Time settings: 5s, 10s, 15s, 20s
Ramp Mode (P5):
Light intensity: 1200mW/cm²
Time settings: 5s, 10s, 15s, 20s
Key Features:
360° Rotatable Head: Easily adjusts to illuminate various treatment areas, making it ideal for precision work in challenging areas like posterior molars.
Compact, Small Light Head: Provides better access and comfort for patients during treatments, especially in hard-to-reach areas.
Special Lens Design: The unique lens forms a concentrated, uniform beam, ensuring thorough curing of dental materials.
Broad Spectral Range (380-515nm): The PEN-E’s broad spectrum is effective across various resin types, including those using alternative initiators like TPO, ensuring consistent curing performance.
Ultra Power Output: Achieves a light intensity of up to 3000mW/cm², providing fast, deep curing even for thick layers of dental materials.
Technical Specifications:
Dimensions: 19 x 16.5 x 7.5 cm
Weight: 120g
Lens Size: 8mm
Power Supply: Supports over 1200 uses (3000mW/cm², 3-second exposure)
